SilverStone Technology RM51 5U Rackmount Server Chassis - Dual 180mm Fans & Enhanced Liquid Cooling Support | High-Performance Server Case for Data Centers, IT Racks & Enterprise Storage Solutions (SST-RM51)
SilverStone Technology RM51 5U Rackmount Server Chassis - Dual 180mm Fans & Enhanced Liquid Cooling Support | High-Performance Server Case for Data Centers, IT Racks & Enterprise Storage Solutions (SST-RM51)
SilverStone Technology RM51 5U Rackmount Server Chassis - Dual 180mm Fans & Enhanced Liquid Cooling Support | High-Performance Server Case for Data Centers, IT Racks & Enterprise Storage Solutions (SST-RM51)
SilverStone Technology RM51 5U Rackmount Server Chassis - Dual 180mm Fans & Enhanced Liquid Cooling Support | High-Performance Server Case for Data Centers, IT Racks & Enterprise Storage Solutions (SST-RM51)
SilverStone Technology RM51 5U Rackmount Server Chassis - Dual 180mm Fans & Enhanced Liquid Cooling Support | High-Performance Server Case for Data Centers, IT Racks & Enterprise Storage Solutions (SST-RM51)
SilverStone Technology RM51 5U Rackmount Server Chassis - Dual 180mm Fans & Enhanced Liquid Cooling Support | High-Performance Server Case for Data Centers, IT Racks & Enterprise Storage Solutions (SST-RM51)
SilverStone Technology RM51 5U Rackmount Server Chassis - Dual 180mm Fans & Enhanced Liquid Cooling Support | High-Performance Server Case for Data Centers, IT Racks & Enterprise Storage Solutions (SST-RM51)
SilverStone Technology RM51 5U Rackmount Server Chassis - Dual 180mm Fans & Enhanced Liquid Cooling Support | High-Performance Server Case for Data Centers, IT Racks & Enterprise Storage Solutions (SST-RM51)
SilverStone Technology RM51 5U Rackmount Server Chassis - Dual 180mm Fans & Enhanced Liquid Cooling Support | High-Performance Server Case for Data Centers, IT Racks & Enterprise Storage Solutions (SST-RM51)
SilverStone Technology RM51 5U Rackmount Server Chassis - Dual 180mm Fans & Enhanced Liquid Cooling Support | High-Performance Server Case for Data Centers, IT Racks & Enterprise Storage Solutions (SST-RM51)
SilverStone Technology RM51 5U Rackmount Server Chassis - Dual 180mm Fans & Enhanced Liquid Cooling Support | High-Performance Server Case for Data Centers, IT Racks & Enterprise Storage Solutions (SST-RM51)
SilverStone Technology RM51 5U Rackmount Server Chassis - Dual 180mm Fans & Enhanced Liquid Cooling Support | High-Performance Server Case for Data Centers, IT Racks & Enterprise Storage Solutions (SST-RM51)
SilverStone Technology RM51 5U Rackmount Server Chassis - Dual 180mm Fans & Enhanced Liquid Cooling Support | High-Performance Server Case for Data Centers, IT Racks & Enterprise Storage Solutions (SST-RM51)
SilverStone Technology RM51 5U Rackmount Server Chassis - Dual 180mm Fans & Enhanced Liquid Cooling Support | High-Performance Server Case for Data Centers, IT Racks & Enterprise Storage Solutions (SST-RM51)
SilverStone Technology RM51 5U Rackmount Server Chassis - Dual 180mm Fans & Enhanced Liquid Cooling Support | High-Performance Server Case for Data Centers, IT Racks & Enterprise Storage Solutions (SST-RM51)
SilverStone Technology RM51 5U Rackmount Server Chassis - Dual 180mm Fans & Enhanced Liquid Cooling Support | High-Performance Server Case for Data Centers, IT Racks & Enterprise Storage Solutions (SST-RM51)
SilverStone Technology RM51 5U Rackmount Server Chassis - Dual 180mm Fans & Enhanced Liquid Cooling Support | High-Performance Server Case for Data Centers, IT Racks & Enterprise Storage Solutions (SST-RM51)
SilverStone Technology RM51 5U Rackmount Server Chassis - Dual 180mm Fans & Enhanced Liquid Cooling Support | High-Performance Server Case for Data Centers, IT Racks & Enterprise Storage Solutions (SST-RM51)
SilverStone Technology RM51 5U Rackmount Server Chassis - Dual 180mm Fans & Enhanced Liquid Cooling Support | High-Performance Server Case for Data Centers, IT Racks & Enterprise Storage Solutions (SST-RM51)
SilverStone Technology RM51 5U Rackmount Server Chassis - Dual 180mm Fans & Enhanced Liquid Cooling Support | High-Performance Server Case for Data Centers, IT Racks & Enterprise Storage Solutions (SST-RM51)

SilverStone Technology RM51 5U Rackmount Server Chassis - Dual 180mm Fans & Enhanced Liquid Cooling Support | High-Performance Server Case for Data Centers, IT Racks & Enterprise Storage Solutions (SST-RM51)

$198.37 $360.69 -45% OFF
Size:
2U
6U
4U
5U

Free shipping on all orders over $50

7-15 days international

11 people viewing this product right now!

30-day free returns

Secure checkout

76705859

Guranteed safe checkout
amex
paypal
discover
mastercard
visa
apple pay

Description

In 2019, RM42-502 was released as SilverStone’s first 4U rackmount with 240mm liquid cooling radiator support, followed by the release of RM44 which featured enhanced radiator support of up to 360mm and greater hardware compatibility. Fast forward to 2023, the release of RM51 brings yet another new take in rackmount chassis design with radiator compatibility, while also moving to a larger size – 5U form factor. RM51 is designed for maximum compactness and space optimization, which supports motherboard of up to SSI-EEB, graphics card clearance of up to 455mm and power supply clearance of 190mm. With an added 1U height compared to previously released 4U chassis', allows for much greater cooling potential, which supports 2 x 180mm fans at the front (2 x Air Penetrator 184i PRO pre-installed) which is downward compatible with 3 x 120mm fans and up to 360mm liquid cooling radiator. Alike RM44, a graphics card retainer is included with reserved storage drive mounting holes which prevents sagging and moving of graphics cards while supporting up to 2 x 3.5" HDDs or 3 x 2.5" SSDs. A removable drive cage is included to support 2 x 3.5" HDDs - if unoccupied and left unused, opens up the option of a secondary SFX or SFX-L PSU to be installed. The internal chassis also includes 4 x 2.5" SSD trays, so the chassis supports up to 7 x 2.5" SSDs or 4 x 3.5" HDDs and 4 x 2.5" SSDs. Other notable features include reserved mounting holes for sliding rails, 1 x USB Type-C interface, 8 x expansion slot, and last but not least, case feet are also included which allows the users to opt for a vertical placement instead of the usual horizontal orientation. Overall, RM51 is a feature-packed and highly functional rackmount chassis with unparalled compactness and space utilization.

Features

    Supports up to SSI-EEB / True Extended ATX (12" x 13") motherboards

    Includes two Air Penetrator 184i PRO 180mm fans for superior air intake volume

    Supports up to 360mm liquid cooling radiator

    Available 8 rear expansion slots

    Pre-drilled mounting holes for quick rail installation (compatible with RMS05-22)

    Includes handle and feet for use in horizontal or upright positions

    Optional secondary power supply mount in place of 3.5" drives in dual-propose cage

Reviews

******
- Verified Buyer
Pros:1) Only NAS chassis I'm aware of with 12 hot-swappable drive bays + 120mm to 360mm radiator support. Most other chassis either give you a lot of drive bays with limited CPU cooler support, or have a wide range of CPU cooler support, but limited drive bays.2) Built like a tank. I don't have this in a server rack mount, so its been taking its fair share of beating when I've had to move it around, but its sturdy as hell.Cons:1) Built like a tank. This thing is heavy even without all 12 bays populated...2) Very sharp corners and panel edges. I hope SilverStone takes some time to find ways to round off the sharp corners and panel edges. I can see someone cutting themselves when rotating this around for maintenance since its already so heavy.Other Notes:Someone else mentioned that the 3 OEM 80mm x 15mm hard drive fans are noisy. They are. According to the manuals the default fan profile when the fan headers are plugged into the backplane is drive temps >= 45C means 99%-100% fan speed. 12 fully populate bays will mean your drives will be 45C or more, so I wouldn't recommend using the backplane fan headers unless you like your fans always at basically 100%I did try a bunch of different brands of fans to test out, and the OEM fans are probably the best 80mm x 15mm fans to have in terms of noise to cooling capabilities.I tried 3 Noctua NF-A8s (80mm x 25mm) mounted behind the backplane bracket towards the PSU (compared to the OEM fans being mounted in front of the backplane bracket towards the backplanes), and while those were definitely quieter they could not sufficiently cool down twelve 3.5in drives without being on 100% speed (and at that point you can definitely hear them).If you want to mount 80mm fans from other brands in the same orientation as the OEM fans then you can get away with anything up to 80mm x 20mm. Otherwise you can go up to 80mm x 25mm without issues when mounting the fans behind the backplane fan bracket towards the PSU.You can technically go as deep as 80mm x 38mm when mounting the fans behind the backplane fan bracket instead of the default OEM orientation, but you may run into some issues with thread holes from the mobo preventing flush mounting of your fans.I settled on 3 Sanyo Denki 9GA0812P1H611 80mm x 38mm fans (mounted slightly crooked) at 6% - 14% duty cycle. That is sufficient for keeping all 12 drives between 38C and 45C during heavy drive loads while keeping the noise as low as possible.
